Polytherm 10 Port Underfloor Heating Manifold
In stock
Product Code
U35702
A fully furnished manifold centre for heating circuits light and durable, with stainless steel body made according to EN 10088-2, Material: 1.4301 (X5CrNi18-10):
Features:
2 x air vents 1/2, nickel-plated.
2 x filling/draining valves 1/2", nickel-plated, plastic black.
2 x end caps 1", nickel-plated.
For each circuit: connector nipples 3/4" (male connection), Eurocone, DIN V 3838, nickel-plated.
Distance between the circuits: 50 mm.
2 x connections to the rest of the system with 1" union nuts (female connection), nickel-plated.
Outflow: manifold with adjustable flow meters Type RL-V-0-5 l/min to regulate the water flow.
Return: manifold with Thermostatic valves for each circuit, hand wheels blue.
2 x mounting brackets, completely with screws and plugs in the package (brackets are not mounted on manifolds)"
Features:
2 x air vents 1/2, nickel-plated.
2 x filling/draining valves 1/2", nickel-plated, plastic black.
2 x end caps 1", nickel-plated.
For each circuit: connector nipples 3/4" (male connection), Eurocone, DIN V 3838, nickel-plated.
Distance between the circuits: 50 mm.
2 x connections to the rest of the system with 1" union nuts (female connection), nickel-plated.
Outflow: manifold with adjustable flow meters Type RL-V-0-5 l/min to regulate the water flow.
Return: manifold with Thermostatic valves for each circuit, hand wheels blue.
2 x mounting brackets, completely with screws and plugs in the package (brackets are not mounted on manifolds)"
| Brand | Polytherm |
|---|---|
| Manufacturer Part Code | 500200010 |
| Product Type | Manifold |
